KE3100 xDSL Detection Kit

Flexible test cord 25 cm Test cord connections 2x banana with crocodile clips 1x RJ11 plug with TAE adapter 1x RJ45 plug Additional test ports 1x 2,5 mm universal optical fibre ferrule (KE895) Features Continuity test LED   tone DSL availability test for services according to ITU-T G.441 such as ADSL – ADSL2 , SHDSL, VDSL2, VDSL 35b, G.fast Resistance test by changing the tone frequency Low battery indication by flashing LED Auto power off 45 / 90 min. / never (in toner mode) Device switch-on indicator with LED Data port test via Link-Blink function Visible laser light source (VFL) (KE895) Frequencies Copper (<±1 %) Solid: 1 kHz, 1,9 kHz, 577 Hz Frequencies Fibre 270, 1000 Hz moduliert pulse (KE895) Ranger Copper Max. cable length up to 15 km without load, up to 0.4 mm Ø Range Fibre Max. cable length up to 10 km (KE895) Transmitting power (9 V block battery) 9.0 VSS without load / ~ 12 VSS with loaded battery 5 dBm at 600 Ohm for fundamental 1 kHz 0 dBm at 100 Ohm for fundamental 1 kHz -5 dBm at 50 Ohm for fundamental 1 kHz Overvoltage protection Up to 500 V DC / 350 V AC in all modes except CONT and ETH for banana plugs / Pin 4   5 on RJ45 Dimensions 150 x 65 x 26 mm Weight 220 g without battery Case Solid, shock-resistant and weather-resistant ABS-case Detached battery compartment Captive Screw
